What Hp Are Stock Injectore Good For?


This topic has been archived. This means that you cannot reply to this topic.
19 replies to this topic

#1 Iloveboost

Iloveboost

    Level 2 Member

  • Members
  • PipPip
  • 521 posts

Posted 27 September 2009 - 01:57 AM

I have a 94 850 turbo and was wondering what hp the stock orange injectors are good for?
Posted Image
Underhill, VT 2002 S60 T5 5 speed. 2000 Honda CBR 929RR



#2 rbodor3

rbodor3

    Level 3 Member

  • Members
  • PipPipPip
  • 1,058 posts

Posted 27 September 2009 - 02:08 AM

Volvo Resource page

01 Volvo S60 LPT Powered by ARD
3" DP & back | ipd sways and links | Bilstein & Eibach sport | R - BBK | B&M Cooler | 19T | ipd CBV | Quaife | M56lk | greens | FMIC | Snabb | ACD TCV | ARD crank pulley | built | alum rad


#3 jschaefer7406

jschaefer7406

    Level 2 Member

  • Members
  • PipPip
  • 962 posts

Posted 27 September 2009 - 02:31 AM

Hello,

There is a great calculator located here:

http://www.witchhunt...ectorcalc1.php4

This site is full of resources reguarding injectors. Covers everything from injector size calculations to stock injector flow rates (listed by Bosch P/N). Using the calculator on the linked page, you should be able to plug in different HP numbers and find the injector flow to match (stock 850T injectors are roughly 310cc's @ 43.5 psi). Kind of a backwards calculation, but it works. It kind of goes against everyones "one HP for each cc" theory, as there's no way a 310cc injector will be sufficient for 310HP on a turbo engine. If that were the case, no one would bother upgrading to whites or blues :).

Good luck,

Joe

#4 turbor850

turbor850

    i am the new pegs

  • Supporting Member
  • 4,191 posts

Posted 27 September 2009 - 03:02 AM

or . . your injectors could be sized for each turbo (used as a minimum could always go bigger) -

15G - Orange
16T - Orange
18T - Whites
19T - Whites
K24 - Blues/Green
16G - Blues/Green
20G - Green/550 cc RC Eng.
GT30R/3071R - 550 cc RC Eng.
GT42R - Red (J/K!)

The Old Sold 850R - Dyno Tuned To ~ 340whp 388wtq @ 22.5 psi - 20G - AUTO - Mustang Dyno - EPL #1 Cheerleader

Current Cars : 2013 VW GLI - Intake / Intercooler Piping

                          2007 Shelby GT500 - Stock


#5 MyCarIsRed

MyCarIsRed

    Level 3 Member

  • Members
  • PipPipPip
  • 1,526 posts

Posted 27 September 2009 - 02:57 PM

or . . your injectors could be sized for each turbo (used as a minimum could always go bigger) -

15G - Orange
16T - Orange
18T - Whites
19T - Whites
K24 - Blues/Green
16G - Blues/Green
20G - Green/550 cc RC Eng.
GT30R/3071R - 550 cc RC Eng.
GT42R - Red (J/K!)


and the 13t comes with reds... why did they bother making an injector only +5cc more than the orange?

#6 randomdude

randomdude

    ?

  • Members
  • PipPipPip
  • 2,383 posts

Posted 27 September 2009 - 07:07 PM

It kind of goes against everyones "one HP for each cc" theory, as there's no way a 310cc injector will be sufficient for 310HP on a turbo engine. If that were the case, no one would bother upgrading to whites or blues :).



not entirely true. people are often upgrading for the extra margain of safety, or so that the injectors arent running at 100% duty cycle.
my 854T5 with a nice list of mods was totaled by a dumb girl driver :(

1991 780TIC-RARE!-named "roxanne" by the GF.-more pressure-less restrictions-plenty of suspension bits to come!

#7 jschaefer7406

jschaefer7406

    Level 2 Member

  • Members
  • PipPip
  • 962 posts

Posted 27 September 2009 - 07:51 PM

not entirely true. people are often upgrading for the extra margain of safety, or so that the injectors arent running at 100% duty cycle.


Hello,

Absolutely, I agree with you. I have a set of blues that I intend to run with my 15G and (soon) 12 psi tune on my 2000 S70. The stock oranges likely would have been fine for such a mild application, but I like the security of a little more fuel potential if needed. I figure, Volvo used the whites and blues on the HPT cars for a reason. If the oranges were enough for the HPT cars as well, they could have saved lots of money and went with a single injector rating.

I still am not 100% sold on the "one for one" theory though, as every injector calculator I have used (and I've used several) has indicated that I need a 395cc injector, not the 315cc units that I currently have. That is with the aim of only 230-235 flywheel hp, nothing extreme. They could all be wrong I suppose, but they are taken from very reputable sources and all give the same result.

Thanks,

Joe

#8 turbotuner

turbotuner

    Level 1 Member

  • Members
  • Pip
  • 206 posts

Posted 27 September 2009 - 09:33 PM

Hello,

There is a great calculator located here:

http://www.witchhunt...ectorcalc1.php4

This site is full of resources reguarding injectors. Covers everything from injector size calculations to stock injector flow rates (listed by Bosch P/N). Using the calculator on the linked page, you should be able to plug in different HP numbers and find the injector flow to match (stock 850T injectors are roughly 310cc's @ 43.5 psi). Kind of a backwards calculation, but it works. It kind of goes against everyones "one HP for each cc" theory, as there's no way a 310cc injector will be sufficient for 310HP on a turbo engine. If that were the case, no one would bother upgrading to whites or blues :).

Good luck,

Joe


Has anyone actually tried these online calculators with a stock car? Let's plug the numbers in for a stock 850 R manual, which makes 250 hp with white 350 cc injectors:

Power (flywheel) = 250 hp
Number of Injectors = 5
B.S.F.C. = 0.60 - 0.65 (as specified in the notes for a turbo engine)
Max Duty Cycle = 80%

Hit calculate and it says you need injectors which flow between 394 cc and 427 cc/min.

So, according to this calculation, the 350 cc injectors supplied by Volvo would not be anywhere near big enough to make 250 hp, yet we all know that it can make 250 hp all day long!!!

Would anybody like to provide some clues as to why this formula fails for a stock 850R? And if it fails for a stock car, why should anybody consider using it as a guide for modded cars?

I should point out that the above was of course done with two seperate calculations. One with BSFC = 0.60 and another calculation with BSFC = 0.65 which gave 394 cc/min and 427 cc/min respectively.
Turbo-Tuner USB - DIY Tuning for Volvo Bosch Motronic 4.3 and 4.4
http://www.turbo-tuner.co.uk
http://support.turbo-tuner.co.uk

#9 turbotuner

turbotuner

    Level 1 Member

  • Members
  • Pip
  • 206 posts

Posted 27 September 2009 - 10:21 PM

=================================================================================

OK, now lets throw another spanner in the works... :)

We all know that all the well know tuners can make 275 hp on a stock 850 T5 with just a remap. We also know that a stock 850 T5 has orange 315 cc injectors.

So, lets plug some numbers in to see what is required to get 315 cc if you want 275 hp:

Max Power = 275 hp
Injectors = 5
B.S.F.C. = 0.6
Max Duty cycle = 110%

Hit calculate and you get: Injectors required = 315 cc

Wow!!! So, according to this injector calculator, RICA, MTE etc would need to run the injectors at 110% duty cycle to get 275 hp from just a remap. Now, unless I'm mistaken, 110% IDC is impossible!!!

So, let's for the sake of argument bring the duty cycle back down to 80%, since responsible tuners MTE or RICA would never dream of overdriving injectors right? :)

OK, so the new numbers are:

Max Power = 275 hp
Injectors = 5
B.S.F.C. = 0.436
Max Duty cycle = 80%

Injectors reqired = 315 cc

Tada!!! 275 hp can be reached at 80% duty cycle using 315 cc injectors, if the BSFC = 0.436

With me so far? It looks like the BSFC recommended values are wrong since this online calculator states that BSFC should be 0.60-0.65 for turbo engines. Let's therefore assume 0.436 as the new correct BSFC and see if it's possible to get 300 hp on 315 cc injectors...

Max Power = 300 hp
Injectors = 5
B.S.F.C. = 0.436
Max Duty cycle = 87%

Injectors required = 316 cc, assuming BSFC = 0.436

Voila! :)
Turbo-Tuner USB - DIY Tuning for Volvo Bosch Motronic 4.3 and 4.4
http://www.turbo-tuner.co.uk
http://support.turbo-tuner.co.uk

#10 Iloveboost

Iloveboost

    Level 2 Member

  • Members
  • PipPip
  • 521 posts

Posted 27 September 2009 - 10:45 PM

K thanks a lot guys. The reason i asked is because i have a 17 psi tune for my 15g and was wondering if it would be worthwhile to get whites.
Posted Image
Underhill, VT 2002 S60 T5 5 speed. 2000 Honda CBR 929RR

#11 turbor850

turbor850

    i am the new pegs

  • Supporting Member
  • 4,191 posts

Posted 27 September 2009 - 11:51 PM

K thanks a lot guys. The reason i asked is because i have a 17 psi tune for my 15g and was wondering if it would be worthwhile to get whites.


Upgrading to a 18/19T in the future ? IF yes, then grab some whites.

The Old Sold 850R - Dyno Tuned To ~ 340whp 388wtq @ 22.5 psi - 20G - AUTO - Mustang Dyno - EPL #1 Cheerleader

Current Cars : 2013 VW GLI - Intake / Intercooler Piping

                          2007 Shelby GT500 - Stock


#12 jschaefer7406

jschaefer7406

    Level 2 Member

  • Members
  • PipPip
  • 962 posts

Posted 28 September 2009 - 02:05 AM

=================================================================================
Tada!!! 275 hp can be reached at 80% duty cycle using 315 cc injectors, if the BSFC = 0.436

With me so far? It looks like the BSFC recommended values are wrong since this online calculator states that BSFC should be 0.60-0.65 for turbo engines. Let's therefore assume 0.436 as the new correct BSFC and see if it's possible to get 300 hp on 315 cc injectors...


Hello,

Not sure if that post was serious or just sarcasm, but here goes :D. Every calculator that I have found recommends a minimum of .60 for BSFC on a turbocharged engine, with .65 being ideal. It's not an error on the afore-mentioned site, just the facts. I am not arguing that oranges aren't good for anything more than stock, but I do think the answer lies somewhere in the middle. I agree that the calculator shows that stock oranges are not even sufficient for the engine they came with :). With a 17 psi tune though, I'd feel very insecure about running orange's if it were me...

Joe

#13 turbotuner

turbotuner

    Level 1 Member

  • Members
  • Pip
  • 206 posts

Posted 28 September 2009 - 07:20 AM

Hello,

Not sure if that post was serious or just sarcasm, but here goes :D. Every calculator that I have found recommends a minimum of .60 for BSFC on a turbocharged engine, with .65 being ideal. It's not an error on the afore-mentioned site, just the facts. I am not arguing that oranges aren't good for anything more than stock, but I do think the answer lies somewhere in the middle. I agree that the calculator shows that stock oranges are not even sufficient for the engine they came with :). With a 17 psi tune though, I'd feel very insecure about running orange's if it were me...

Joe


It was a serious post, done in a fun way! :)

The main point was that if this online injector calculator is showing that stock orange/white injectors are insufficient for a stock car (when we clearly know that they are sufficient), what use is the online calculator? The online calculator must work for stock and modified cars, otherwise it's useless and just misleads people.
Turbo-Tuner USB - DIY Tuning for Volvo Bosch Motronic 4.3 and 4.4
http://www.turbo-tuner.co.uk
http://support.turbo-tuner.co.uk

#14 randomdude

randomdude

    ?

  • Members
  • PipPipPip
  • 2,383 posts

Posted 28 September 2009 - 07:26 AM

if there is someone you should listen to, its probably ^this^ person, lol.
my 854T5 with a nice list of mods was totaled by a dumb girl driver :(

1991 780TIC-RARE!-named "roxanne" by the GF.-more pressure-less restrictions-plenty of suspension bits to come!

#15 Pops Racer

Pops Racer

    Old Man Crew Leader

  • Supporting Member
  • 4,804 posts

Posted 28 September 2009 - 04:13 PM

I love Turbotuner, he makes learning so much fun! And he knows his stuff, y'all.
Government is not reason; it is not eloquent; it is force. Like fire, it is a dangerous servant and a fearful master.

George Washington, remember him, the UN-Obama?

#16 EricF

EricF

    tbricks spy

  • OH Moderator
  • 4,278 posts

Posted 28 September 2009 - 05:07 PM

Hello,

Not sure if that post was serious or just sarcasm, but here goes :D. Every calculator that I have found recommends a minimum of .60 for BSFC on a turbocharged engine, with .65 being ideal. It's not an error on the afore-mentioned site, just the facts. I am not arguing that oranges aren't good for anything more than stock, but I do think the answer lies somewhere in the middle. I agree that the calculator shows that stock oranges are not even sufficient for the engine they came with :). With a 17 psi tune though, I'd feel very insecure about running orange's if it were me...

Joe


Hi Joe,

I took datalogs of an 850 of mine from the past, running orange injectors. Wideband air/fuel readouts showed a maximum value of ~12.7-12.8:1 with a 19T turbocharger including boost spikes up to 26-27 psi. Same car ran 13.3 in the quarter mile at almost 108 mph trap speed in full daily driver weight with 2/3 a tank of gas and my canoe load bars on the roof.

Stock 850 turbo injectors.

Put that in the pipe and smoke it :lol:

I am certain that car saw duty cycles of 100% fairly often. I had an injector freeze open once. Tapped it with a wrench and it fixed itself. Not recommended, but I also had a wideband air/fuel gauge on that car and it *never* ran lean under WOT high boost conditions.

Not that I would recommend trying to get that much out of the orange injectors, but I am primarily saying that just because an online calculator says something does not mean it is an absolute truth. 'Reputable' and 'trusted' as they may be... I am sure the creators of these calculators use them to help guide people in putting together new hardware setups. We do not for the most part do that at Volvospeed. We turn up the boost and upgrade our compressor wheels, that's mainly it. Stick with general knowledge unless you are going beyond the realm of general knowledge ;)


As an aside, my current 850 has 350cc/min blue injectors, with the base fuel pressure at 52-54 psi. It's around 390-400cc/min effective flow rate. I am currently running very rich air/fuel ratios and would give you $10 if I strapped the car to a dyno tomorrow and didn't make 300 whp (~330-340 bhp).

Anyway take that whichever way you'd like, but do know that if you run a larger injector than your tune specifies, you will lose a lot of power and be running very rich across the board. If you still haven't purchased your tune, please make sure that the tuner knows which injectors you will be using.

1995 850 turbo - M56H, KW V2, being de-tuned

"Fish, I love you and respect you very much. But I will kill you dead before this day ends." -Santiago


#17 Che'_Moderator

Che'_Moderator

    Monkey Master

  • Admin
  • 24,866 posts

Posted 28 September 2009 - 05:20 PM

/em shakes head

"How much HP does this injector makes" depends on the engine. 700cc will be good for only about 2hp in a 1 % efficient engine. If you want to go by theoretical limits they are good for about 440 hp on a 99% effecient engine running 13:1 at 100% peak hold. Real world they are good for ~350bhp....... or 280bhp on a ST chip :lol:

#18 Iloveboost

Iloveboost

    Level 2 Member

  • Members
  • PipPip
  • 521 posts

Posted 28 September 2009 - 08:41 PM

Thanks for the responses guys. I went ahead and ordered the whites.
Posted Image
Underhill, VT 2002 S60 T5 5 speed. 2000 Honda CBR 929RR

#19 Wagoneer855

Wagoneer855

    Level 4 Member

  • Supporting Member
  • 3,186 posts

Posted 28 September 2009 - 09:36 PM

Remember that it's not the same once you start talking about the 2.4 blocks with 9:1CR. My stock reds couldn't keep up at 17psi with a 16T.
'97 855 - Build in progress

#20 Cal3thousand

Cal3thousand

    Level 3 Member

  • Lifetime Supporter
  • 2,065 posts

Posted 29 September 2009 - 09:22 PM

and the 13t comes with reds... why did they bother making an injector only +5cc more than the orange?



I thought REDs were 300cc making them 10cc LESS than orange.
